| MOQ: | 1 unit |
| Price: | USD5000~USD50000 |
| Standard Packaging: | Standard export packaging |
| Supply Capacity: | 100 units +3weeks |
XS143J has a very high static line load and exciting force and is suitable to the compaction operation of pebbles, sandy soils, moraine soil, blasting rock and clayey soil, etc,
it is also suitable to the compaction of concrete and stabilized soil base materials in various large projects, with the maximum working depth up to 1.0m and above. Thus, it is a kind of important compaction equipment in the construction of large projects such as the expressway, railway, port, etc.
Product introduction
Overall parameters reasonably matched and optimized,low-speed engine and hydraulic damping control technology contributes to significant reduced consumption and emissions;
Centered static and dynamic forces and optimized transmission system effectively improves compaction performance and efficiency;
It exclusives open loop two-frequency vibration system enables wide-ranging applications;Container transportable;
Detachable cabin with ROPS,safe and reliable,easy to disassemble and assemble.
| ltem | Content | Unit | XS143J |
| Weights | Operating weight | kg | 14000 |
| Maximum operating weight | kg | 14420 | |
| Front axle weight | kg | 7300 | |
| Rear axle weight | kg | 6700 | |
| Static linear load | N/cm | 315 | |
| Maneuverability | Working speed(F/R) | km/h | 2.85/5.08/11.172.88/5.02 |
| Grade ability | % | 30 | |
| Minimum turning radius(outer | mm | 6800 | |
| Minimum ground clearance | mm | 431 | |
| Wheel base | mm | 3040 | |
| Steering angle | 33 | ||
| Oscillation angle | 11 | ||
| Compaction parameters | Vibration frequency | Hz | 28/33 |
| Nominal amplitude | mm | 1.9/0.95 | |
| Excitation force (high/low frequency) | kN | 274/190 | |
| Drum diameter | mm | 1523 | |
| Drum width | mm | 2130 | |
| Engine | Mode | - | SC4H140.1G2 |
| Emission | - | China stageⅡ | |
| Rated power | kW | 103 | |
| Rated speed | r/min | 1800 | |
| Tire | Spec | 20.5-25-16PA | |
| Ply rating | - | 16 | |
| Air pressure | kPa | 350 | |
| Capacities | Fuel tank | L | 310 |
| Urea tank | L | / |
| Truck Crane | KATO | NK200E, NK250E, NK300E, NK400E, NK500E, NK800E, NK1000, NK1200, NK1200E |
| TADANO | TG250, TL250, TL250E, TL300E, TG300E, TG350E, TG450E, GT550E, TG550E, TG650E, GT650E, | |
| Rough terrain Crane | KATO | KR25H, KR45H, KA300, SS500.KR250E, KR450 |
| TADANO | KR250E,KR350E, TR250M, TR300M, AZ300D, AR350, TR450E, TR500M | |
| Crawler Crane | HITACHI | KH700, KH120T, KH125, KH150, KH180 |
| KOBELCO | 50T, 100T, 120T, 300T | |
| SUMITOMO | 50T, 100T, 200T | |
| Excavator | Hitachi | EX100, EX100WD, EX120, EX200, EX200LC, EX220, EX300, EX350, EX450, ZX70, ZX120, ZX150 |
| Caterpillar | 200, 235, 305, 307, 312, 320, 330, 324, 325, 345 (From Model B to Model D) | |
| Komatsu | PC50, PC60, PC100, PC120, PC130, PC200, PC210, PC220, PC300, PC350, PC400, PC450 | |
| Kobelco | SK100, SK120, SK200, SK350 | |
| Daewoo | DH55, 60, 130, 150, 220, 225, 300 | |
| Hyundai | 130w, 150w, 200, 210, 220, 225, 290, 305 | |
| Volvo | EC210, 240, 290,360,460,700 | |
| Loader | Caterpillar | 916, 924, 928, 936, 938, 950, 966, 980, 988 (From Model C to Model H) |
| Komatsu | WA100, 230, 250, 300, 320, 350, 360, 380, 400, 430, 470 | |
| Kawasaki | 70, 70B, 80Z, 85Z, 90, 90Z, 95Z | |
| Backhoe Loader | JCB3CX, JCB4CX, CAT416,CAT428 | |
| Bulldozer | Caterpillar | D6D, D6H, D6R, D6G, D7H, D7G, D7R, D8K, D8R, D8N, D8L, D9N, D9R, D10N |
| Komatsu | D50P, D60P, D65, D85, D155 | |
| Motor Grader | Caterpillar | 12G, 14G, 120G, 140G, 16G, 140H, 160H, 140K |
| Komatsu | GD511A, 605A, 623 |
Packaging and shipping
1. Containers are the cheapest and fastest
2. Bulk carriers are better for large construction equipment
3. Flat rack is better for large construction equipment and does not need to be disassembled
4.RoRo ships are fast and good for all kinds of machines
You can choose any transportation according to your needs
5. FOB, CRF and CIF are all acceptable.
We can ship the machine in bulk as a whole, or we can load it in a container and disassemble it on some parts of the machine, or we can ship it on a flat rack. We can choose the way according to your requirements.
Packaging details: Packaging will be as per customer requirements
Delivery time: 2 working days
Experienced international trade team provides the best full set of services
our service
1) Original parts and good working condition;
2) Low working hours and high work efficiency;
3) Strong work motivation and good stability;
4) Complete accessories and no oil leakage;
5) Competitive price and good skills;
6) Good after-sales service
We hope you can give us the opportunity to negotiate with you by email or phone, or come to Shanghai face to face, we are honored to contact you and serve you, and we promise to provide you with the best prices and services:
1) Book a hotel for you
2) Pick you up at the airport
3) Freely translate for you and guide you when you are free
4) 6 months to 1 year product and after-sales service warranty
We can assure you of the quality of our used construction machinery and provide you with the most competitive price since we
have professional staff to search for the cheapest and best machines from all over China. Besides, we have skilled workers to
refine old machines if you need. You are very welcome to come here and inspect by yourselves. Your satisfaction is our priority.
If you are interested in any of our used construction machinery, please feel free to contact us.
1. How to guarantee the condition and lifetime of the machine ?
A: We choose good condtion and less hour used machines. We are available for third part certificate of all of the machines.
And they are all available for your inspection in its place.
2. How to have after sale service from us ?
A: We have old suppliers in China, used or new parts are available for us to get, with reasonable price and in short time.
3. How can customers make visit and checking in China ?
A: We arrange everything ready for your jouney in China, welcome your happy visit!~
|
|
